NÖRDIC HDMI eARC SPDIF Audio extender over CAT6 cable 100m

Hover over the image to zoom in

NÖRDIC HDMI eARC SPDIF Audio extender over CAT6 cable 100m

Name: NÖRDIC HDMI eARC SPDIF Audio extender over CAT6 cable 100m
Brand: NÖRDIC
SKU: SGM-277
Price: 140,00 EUR
Availability: InStock

NÖRDICSKU:SGM-277

The NÖRDIC HDMI eARC and S/PDIF Audio Extender enables the transmission of high-resolution audio signals over long distances via a single CAT6 cable. The product supports both HDMI eARC and optical S/PDIF, providing flexibility for both modern and older TV models. Perfect for transmitting audio from the TV to amplifiers, soundbars, or multi-zone audio systems. Thanks to PoC (Power over Cable), only one power adapter is required for both the transmitter and receiver.

Specifications

Supported audio formats:
- eARC: PCM 2.0/5.1/7.1ch, DD, DD+, DTS, Dolby TrueHD, DTS-HD MA, Dolby Atmos
- ARC: PCM 2.0ch, Dolby 5.1ch, DTS 5.1ch
- S/PDIF: PCM 2.0ch, Dolby 5.1ch, DTS 5.1ch
Transmission distance: up to 100 m via CAT6
CEC pass-through: Yes (in HDMI eARC mode)
EDID copy support
ESD protection: ±8kV (air) / ±4kV (contact)
PoC (Power over Cable): Yes, only one unit requires power
Power consumption: Max 5.65W
Power adapter: AC 100–240V in / DC 12V 1A out (CE/FCC/UL certified)
Operating temperature: 0 – 40 °C
Storage temperature: -20 – 60 °C
Humidity: 20 – 90% RH (non-condensing)

Connections

Transmitter
Input: 1 x eARC IN (HDMI), 1 x S/PDIF IN (optical)
Output: 1 x CAT OUT (RJ45)
Control: 1 x SERVICE port
Power: 1 x DC 12V
Receiver
Input: 1 x CAT IN (RJ45)
Output: 1 x eARC OUT (HDMI), 1 x S/PDIF OUT (optical)
Control: 1 x SERVICE port
Power: 1 x DC 12V

Features

Supports both HDMI eARC and S/PDIF audio
Switching between eARC and S/PDIF via physical switch
Supports daisy chaining to multiple devices
Recommended cable: Shielded CAT6 and High Speed HDMI cable
Plug & play – no driver required

Contents

1 × HDMI Audio Extender (Transmitter)
1 × HDMI Audio Extender (Receiver)
1 × Power Adapter 12V/1A
1 × User Manual
